New Product: T-L Irrigation Gooseneck Cradle Corner System Attachment

Published online: Feb 03, 2022 Articles, Irrigation, New Products
Viewed 1959 time(s)

T-L Irrigation Co. has added a gooseneck cradle corner system attachment option and a simplified auto-reverse system to add stability and durability to two important pivot locations.

“The gooseneck corner cradle option drops the corner connection point by 24 inches,” Neal Schlautman, T-L Irrigation Co. engineering manager. “This lowers the corner span’s center of gravity and greatly improves its stability.” A lower center of gravity allows for greater stability on steep terrain and in areas with high winds or frequent severe storm activity.

“Corner systems seem to be the first to flip in severe weather. Losing a corner to a storm in peak season means not only losing that expensive investment, but possibly also your crop if it can’t be replaced quickly,” says T-L vice president John Thom. “This connection option helps reduce the odds of losing a corner system.”

Irrigators who graze pivots stand to benefit from the simplified auto-reverse for fully hydraulic systems. The new system incorporates over-centered actuation arms to change the position of the reversing valve. The over-center feature assures snap action and full engagement of the reversing valve. The arms have also been moved farther up the tower and out of reach of livestock.

“Livestock can damage the auto-reverse components when attached in the original, lower position,” says Thom. “Moving them halfway up the tower eliminates that problem. Each of these solutions provides improved durability of already reliable T-L systems for a broader range of geographies and uses.”

T-L Irrigation Co. is a family-owned irrigation solutions business based in Hastings, Neb. For 67 years they’ve been committed to providing reliable and high-quality center pivots, irrigation systems, agriculture and irrigation equipment, and innovative water management products that are intuitive for farmers to use and repair. They distribute throughout the U.S. and to 80 countries.

(800) 330-4264

www.tlirr.com
