AGCO Corporation introduces the Hesston by Massey Ferguson RazorEdge 1300 Series pull-type disc mower conditioner. The RazorEdge 1300 Series are heavy-duty, with a fully welded frame for reliability and efficiency even in the toughest hay-cutting conditions. The unique RazorEdge cutter bar ensures a smooth, clean cut, and the hydraulically tensioned conditioner system reduces drying time to optimize crop quality.
“Everything about this rugged, high-capacity mower conditioner series is designed to give operators reliable, trouble-free hay-cutting performance,” says Matt LeCroy, AGCO tactical marketing manager for hay and forages.
RazorEdge 1300 Series pull-type disc mower conditioners replace the previous RazorBar models and include four choices to fit producers’ needs:
- MF1373, a 9-foot, 10-inch side-pull model
- MF1376, a 9-foot, 10-inch center-pivot model
- MF1393, a 13-foot center-pivot model
- MF1395, a 16-foot center-pivot model
Each of the new RazorEdge 1300 Series mower conditioners is equipped with the RazorEdge cutter bar, which has a spur gear design to provide a thin profile and close cutting without tilting the header. This minimizes scalping and limits dirt and debris in the crop to optimize feed value. Scrapers on the cutter bar also help keep the cutter bar clean by sweeping mud and debris off. The cutter bar also has a modular design so each gear assembly and adjacent idler gear can be individually removed without disassembly of the entire cutter bar. Counter-rotating discs provide improved cut quality while minimizing crop streaking.
The heavy-duty, cast iron gearbox is a standard feature on Hesston by Massey Ferguson rotary heads, designed to handle tough conditions and provide long life for these mower conditioners.
Each RazorEdge mower conditioner comes factory-equipped with 18-degree “high lift” bottom-bevel Radura knives. These sharp, durable knives are created with a special cold-rolled process for a wear-resistant edge that maintains its sharpness longer than ground-edge knives. Other knife options also are available through AGCO Parts to match various crop and field conditions. To minimize downtime, an optional quick-change knife system and the handy, new quick-change tool make fast work of replacing cutter bar knives.
The RazorEdge mower conditioners crimp the crop every 3 to 4 inches with a single set of steel-on-steel conditioner rolls. This crimping action breaks open the stem for faster drying while preserving leaf quality. Plus, the herringbone tread design feeds and conditions material more evenly for improved windrow formation, helping optimize crop quality, protein levels and palatability.
In addition to the standard steel-on-steel conditioner rollers, operators may choose rubber-on-rubber conditioner rolls on models 1373 and 1376 and rubber-on-steel conditioner rollers for models 1393 and 1395. The rubber-on-steel conditioner rolls are fully engaged with a rubber top roll and steel bottom roll to crimp plant stems along their entire length, so stems dry at the same speed.
The 1393 and 1395 models use the industry-exclusive hydraulic roll conditioning tension system while models 1373 and 1376 use a spring tensioner to deliver consistent roll pressure. The 1373 and 1376 are also available with or without a tine conditioner.
Learn more at www.masseyferguson.us.
